| Specifications | |||
| Rated Load | Current/Voltage | A/VAC | 16?25/300 |
| Dielectric Strength | Coil & Contacts | V/S | 2000 |
| Between contacts | V/S | 2000 | |
| Wire Size | AWG/mm2 | 20-14/0.5-2.5 | |
| Tightening Torque | Nm | 1.0 | |
| Matched Accessories | |||
| Socket | Relay Type | Module | DIN Rail |
| PEF08A | K-53 | / |  |
| PEF11A | |||
